Description

UPGRADED MODEL! Now with better cellular service!

The Omnitrack was specially designed for the Private Investigator & Law Enforcement Agent to support them during covert surveillance. The powerful, long-life battery and compact “all-in-one” design make the Omnitrack easy to hide and trackable in real-time for up to 5-7 days.

The Omnitrack is perfect for tracking suspects, cheating spouses, fraudulent lawsuit victims, or for any reason you need to know the whereabouts of somebody or something.

Use the magnetic case for a quick, covert installation on a vehicle or choose an extended battery kit for greatly increased battery life. You can get the GPS’s location anytime from anywhere and the web-based platform upgrades at no cost.

Features

• Includes 1 full year of GPS tracking service!
• No contracts, activation fees, or termination fees!
• Up to 5 Geofence boundaries allow agents to be notified via email or text message when a vehicle under surveillance leaves a pre-set boundary.
• Location & status report every 5 minutes in motion
• One-click reporting give the entire story in easy to read spreadsheets.
• Email & SMS alerts keep you informed no matter you are.
• Monitor the location of any vehicle from any computer or smartphone via the Internet.

Technical Specs

• Battery Life: 5-7 days at 2 hours per day (signal strength can affect battery life)
• BC0/BC1 Compliant to CDMA2000-1x
• Max Data Rate 153.6 Kbps
• Max Out RF Power: 23-25 dBm
• Min Out RF Power: < -50 dBm
• Receiving Sensitivity: BC0 -110 dBm, BC1 -107 dBm
• Max Frequency Error: 800MHz band ±300 Hz, 1900 Mhz band: ±150Hz
• GNSS Receiver Type: 72 Channel u-blox M8 Engine
• TTFF (Open Sky): Cold Start 30s, Warm Start: 27s, Hot Start: 1s
• Transmit Protocol: TCP, UDP, SMS
• Charging Voltage: 5V DC
• Internal Battery Li-Polymer 1300mAh, 3.7V
• External Battery Voltage: 3.5V to 4.5V DC
• Dimensions: 78.5×38.5×22.5mm
• Weight: 70g
• IP Rating: Water Resistance IPX5 compliant
• Operating Temperature: -20 degrees Celsius to 55 degrees Celsius

Included

• 1 x Omnitrack
• 1 x DC Charger
• 1 x Instruction Manual
• 1 x Activation Code
• 1 x Magnetic Case (Latest Model Only)
